Lennox 56W68 Replacement Part
Includes:
- (1) – Draft Inducer Motor Assembly (56W68)
- (1) – Installation Instructions (42425J097)
Specifications
- Manufacturer: Fasco
- Model 702110218
- Fasco Motor Type: U21B
- HP: 1/30
- Voltage: 115
- Hertz: 60
- Amperage: 1.4
- Phase: Single
- RPM: 3000
- Thermally Protected
- Insulation Class: B
- Motor Cooling: Air Over
- Motor Duty: Continuous
- Rotation: Clockwise Lead End
- Housing: Metal
Replaces Old Lennox Part Numbers
- R44431-001
Replaces Old Allied, Armstrong, Concord, Ducane Part Numbers:
- R44431-001
- R45403-001
- 20311101
- R41445-001
- R40718-001
- R40425-003
- R40425-002
- R40425-001
- R38494B002
- R38494B001
- R37683C001
- R44431-001
Other Part Numbers
702110218, U21B, 44431-001, M4312, Beckett Air, M4814, LR36496, 44431001, Armstrong, Lennox
FitsModels:
(Press ctrl + F to find model number below.)
CG80RB050D12AL-1, CG80RB075D12AL-1, CG80RB100D20CL-1, CG80TB050D12AL-1, CG80TB075D12AL-1, CG80TB075D16BL-1, CG80TB100D20CL-1, CG80TB125D20C-1
Fits Allied, Armstrong, Concord, Ducane, Magic Chef, and Magic-Pak Models:
(Press ctrl + F to find model number.)
EG5G100DC12-1, EG5G125DC16-1, EG5G150DC20-1, EG5G75DC12-1, EG6G100DC12-4, EG6G100DC13-1, EG6G100DC13-2, EG6G100DC13-3, EG6G100DC20-4, EG6G125DC12-4, EG6G125DC20-1, EG6G125DC20-2, EG6G125DC20-3, EG6G125DC20-4, EG6G150DC20-1, EG6G150DC20-2, EG6G150DC20-3, EG6G150DC20-4, EG6G50DC14-4, EG6G50DC8-1, EG6G50DC8-2, EG6G50DC8-3, EG6G50DC8-4, EG6G75DC10-1, EG6G75DC10-2, EG6G75DC10-3, EG6G75DC10-4, EG6G75DC16-4, EG6G75DC8-4, EG7G100DC14-1, EG7G100DC16-1, EG7G125DC20-1, EG7G150DC20-1, EG7G50DC8-1, EG7G75DC10-1, EG8G100DC14-1, EG8G100DC14-2, EG8G100DC16-1, EG8G100DC20-1, EG8G125DC14-1, EG8G125DC14-2, EG8G125DC20-1, EG8G150DC20-1, EG8G50DC14-1, EG8G50DC14-2, EG8G50DC8-1, EG8G50DC8-2, EG8G75DC10-1, EG8G75DC12-1, EG8G75DC12-2, EG8G75DC16-1
