Lennox Y4749 Replacement Part
Includes:
- (1) – Control Box (BGN891-2)
- (1) – Spade Connector (-)
- (1) – Jumper Wire w/ Resistor (-)
- (1) – Installation Instructions (BASO-INS-BGN891)
Specifications
- Manufacture: Baso
- Model Number: BGN891
- Pre-Purge: 30 Seconds
- Trial: 5 @ 8 Seconds
- Retry Continously every 60 Seconds
- Inter – Purge: 30 Seconds
- Post Purge: 30 Seconds
- Voltage: 24
- Hertz: 50/60
- NEC Class 2
- Valve 4A Max.
- Current Draw: 0.2 Amperage
- Blower Motor: 120/240VAC 6A Max.
- Spark Gap: 0.2 IN. Max
Replaces Old Lennox Part Numbers
- 60J00
- 99C97
- 97H02
- 96C66
- 87F22
- 86H30
- 73K86
- 72H68
- 56G14
- 52J18
- 41F46
- 34K83
- 99C9701PR
- 99C9701
- 96C6601
- 87F2201
- 77C3801
- 56G1401PR
- 41F4601PR
- 34K8301
- 86H3001
- 73K8601
- 72H6801
- 52J1801
Replaces Old Allied, Armstrong, Concord, Ducane Part Numbers:
- There are no older part numbers.
Other Part Numbers
Other Part Numbers:, Baso, BGN891-2, W1209, W1208CR, ANSI Z21.20 Can/CSA-C222, No. 199-M89, BGN891, BASO-INS-NGN891, VSP1-1, BGN891-2C, PRC BGN891-2C Pulse Furnace Replacement Control, TROV000157033, Baso Gas Products LLC, W1344
FitsModels:
(Press ctrl + F to find model number below.)
G14-100-1, G14-130-1, G14-40-15, G14-40-2, G14-40-23, G14-40-3, G14-40-4, G14-40-5, G14-40-6, G14-60-12, G14-60-2, G14-60-20, G14-60-22, G14-60-23, G14-60-3, G14-60-4, G14-60-6, G14-80-1, G14-80-11, G14-80-13, G14-80-3, G14-80-7, G14-80-8, G14-80-9, G14Q3-100-5, G14Q3-40-2, G14Q3-60-12, G14Q3-60-15, G14Q3-60-19, G14Q3CAN-40-1, G14Q3CAN-40-22, G14Q3CAN-40-3, G14Q3CAN-40-4, G14Q3CAN-40-5, G14Q3CAN-60-1, G14Q3CAN-60-22, G14Q3CAN-60-23, G14Q3CAN-60-5, G14Q3CAN-60-6, G14Q3CAN-80-1, G14Q3CAN-80-22, G14Q3CAN-80-3, G14Q3CAN-80-4,G14Q3CAN-80-5, G14Q4/5CAN-100-6, G14Q4/5CAN-100-7, G14Q4CAN-60-1, G14Q4CAN-60-4, G14Q4CAN-60-5, G14Q4CAN-60-6, G14Q4CAN-80-21, G14Q4CAN-80-5, G14Q5CAN-100-6, G14Q5CAN-100-7, G21Q3-40-3, G21Q3-40-4, G21Q3-60-2, G21Q3-80-3, G21Q3-80-4, G21Q4/5-100-3, G21Q4/5-100-4, G21Q4/5-100-5, G21Q4-80-4, G21Q5-100-2, G21Q5-80-2, GCS16W-1353-270-1, GCS16W-1353-270-2, GCS16W-1353-270-4, GCS16W-1353-270-5, GCS16W-1353-270-6, GCS16W-1353-270-7, GHP16-953-2, GHP16-953-3, GHP16-953-180-1, GHP16-953-180-2, GHP16-953-180-3, GSR14Q3-50-1, GSR14Q3-80-3, GSR14Q3-80-4, GSR14Q3-80-5, GSR14Q3-80-7, GSR14Q3-80-8, GSR14Q4/5-100-2, GSR14Q4/5-100-3, GSR14Q4/5-100-5, GSR14Q4/5-100-6, GSR14Q4/5-80-1, GSR14Q4/5-80-10, GSR14Q4/5-80-2, GSR14Q4/5-80-3, GSR14Q4/5-80-4, GSR14Q4/5-80-5, GSR14Q4/5-80-6, GSR14Q4-50-1, GSR14Q4-50-4, GSR14Q4-50-5, GSR14Q4-50-6, GSR14Q4-50-9, GSR21CVS-100-4, GSR21CVS-80-4, GSR21Q3-50-7, GSR21Q3-80-4, GSR21Q4/5-100-7, GSR21Q4/5-100-8, GSR21Q4/5-80-7, GSR21Q4/5-80-8, GSR21Q4-50-7, GSR21Q4-50-8, GSR21V5-100-7, GSR21V5-100-8, GSR21V5-80-12
