Trane KIT16582 Replacement Part
Includes:
- (1) – Inducer (Part Numbers: D342097P01)
- (1) – Integrated Furnace Control (Part Numbers: D343687P02)
- (1) – IFC MOB Bracket (Part Numbers: D343255P01)
- (1) – Inducer – Limit (Part Numbers: B342017P01)
- (1) – Wire Harness (Part Numbers: D342127P10)
- (1) – Igniter SiNi (Part Numbers: D156805P01)
- (1) – Bracket, SiNi Igniter (Part Numbers: A341948P02)
- (3) – Screw, 8-18 AB HWH 3/8 (Part Numbers: N156P1506B)
- (1) – Junction Box Wires (Part Numbers: B342140P02)
- (1) – Transformer Wire – Black (Part Numbers: B341899P01)
- (1) – Transformer Wire – Neutral (Part Numbers: B341899P02)
- (1) – Door switch to IFC Wire (Part Numbers: B341899P06)
- (1) – Furnace Junction Box Ground Wire (Part Numbers: B341899P05)
- (1) – Inducer Limit Insulation (Part Numbers: A341575P01)
- (3) – Inducer to Mounting Bracket Screws (Part Numbers: N154P1616B)
- (2) – Inducer Limit to Inducer Screws (Part Numbers: N192P1306B)
- (4) – Plastic Stand Off (Part Numbers: D343256P01)
- (6) – Wire Tie (Part Numbers: C107736P06)
- (1) – Wiring Diagram (Part Numbers: D344303P04)
- (1) – Installation Instructions (Part Numbers: 18-CH66D1-2)
- (1) – Conversion Label (Part Numbers: D343215P05)
- (1) – Flue Stack Clamp (Part Numbers: A340597P01)
- (4) – Wire Tie (Part Numbers: A138030P01)
Specifications
- Inducer Motor:
- Manufacturer: Fasco
- Fasco Motor Type: U92B1
- Voltage: 33-110
- Hertz: 60-180
- Amperage: 1.0
- RPM: 1500-4700
- Insulation Class B
- Bearings: Sealed Ball
Replaces Old Trane Part Numbers
- KIT15017
Other Part Numbers
D342097P01, D343687P02, D343255P01, B342017P01, D342127P10, D156805P01, A341948P02, N156P1506B, B342140P02, B341899P01, B341899P02, B341899P06, B341899P05, A341575P01, N154P1616B, N193P1306B, D343256P01, C107736P06, D344303P04, 18-CH66D1-2, D343215P05, A340597P01, A138030P01, KIT; INDUCER CONVERSION, INCLUDES INDUCER BLOWER, IGNITER,LIMIT SWITCH, IFC CONTROLAND WIRE HARNESS
Fits Trane and American Standard Models:
(Press ctrl + F to find model number below.)
Various. (Call 734-326-3900 with your model and serial number for more information.)
